Audison Voce II - 3 way Passive Crossover
AVCX 3P - 3 way crossover
TThe Audison AVCX 3P is a three-way passive crossover meticulously engineered to facilitate bi-amplification and seamless integration within the Audison VOCE II series. This crossover is specifically designed to harmonize the performance of the AV 3.0 II midrange speaker with other VOCE II components, ensuring a coherent and balanced soundstage. The AVCX 3P’s design supports distinct amplification of the woofer, midrange, and tweeter, allowing for precise control over each frequency band. This setup is ideal for achieving the optimal blend of sound dynamics and clarity, tailored to the sophisticated setups demanded by modern car audio enthusiasts.
Technical Data:
| Component | 3 Way crossover |
| Size | 146 x 114 x 40 mm |
| Low Pass filter | 250 Hz, 12 dB/oct |
| Band Pass filter | 250 Hz - 2,5 kHz, 12 dB//oct |
| High Pass filter | 2,5 kHz, 12 dB/oct |
| Crossover Controls | Tweeter levels (+2/0/-2 dB) , Midrange levels (0/-3 dB) |
Technical Data
- Brand
- Audison
- Reference
- AUAVCX3P
